| Displacement: | 296.00 ccm (15.19 cubic inches) |
| Engine type: | Liquid-cooled, 4-stroke Parallel Twin |
| Compression: | 10.6:1 |
| stroke: | 62.0 x 49.0 mm |
| Fuel system: | Fuel injection: ΓΈ32 mm x 2 (Keihin),with dual throttle valves |
| Fuel control: | Unleaded petrol/RON 91 |
| Ignition: | Digital |
| Cooling system: | Liquid Cooled |
| Gearbox: | 6-speed |
| Transmission type, final drive: | Chain |
| Driveline: | O-ring chain |
| Frame type: | Tube diamond, steel |
| Rake (fork angle): | 27/93 mm |
| Front suspension: | 37mm telescopic/ Fork . |
| Rear suspension: | Bottom-link Uni-Trak with 5-way adjustable preload / 5.1 in. |
| Front tyre dimensions: | 110/70-17 |
| Rear tyre dimensions: | 130/70-17 |
| Front brakes: | Single 290 mm petal disc with single balanced actuation dual-piston |
| Front brakes diameter: | 290 mm (11.4 inches) |
| Rear brakes: | Single 220 mm petal disc with Dual-piston |
| Rear brakes diameter: | 220 mm |
| Weight incl. oil, gas, etc: | 170.1 kg (374.9 pounds) |
| Seat height: | 785 mm If adjustable, lowest setting. |
| Overall height: | 1,110 mm (43.7 inches) |
| Overall length: | 2,015 mm (82.1 inches) |
| Overall width: | 715 mm (28.1 inches) |
| Wheelbase: | 1,400 mm (55.1 inches) |
| Fuel capacity: | 17 litres (4.80 gallons) |
